Item description
Materials:
Body: anodized aluminium, internal parts: aluminium and stainless steel, seals: plastic and NBR

Temperature range:
-10 to +70 °C

Media:
oiled and unoiled filtered compressed air

Pressure input:
Connection 1 (type with spring return, possible at every connection)
Properties
Ver­sion Stan­dard
Re­set­ting by Spring (NC/NO)
Thread (2x) G 1/8"
Thread ex­haust air (1x) G 1/8"
Thread con­trol con­nec­tion (1x) G 1/8"
Nom­i­nal width [mm] 6
flow [l/min] 750
Op­er­at­ing pres­sure [bar] -0.95 to 10
Con­trol pres­sure [bar] 2 - 10
Further information on P05312
Weight 160 g / pcs
GTIN 4050571537890
Customs duty number 84812090
RoHS compliant Yes
Manufacturer Airtec (WEEE DE94696834 )
Documents


All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
