3/2-way solenoid valve, G 1/4", pulse valve, 12 V DC
Item number:
RV 3222-08-12V=
Item description
Materials:
Body and slider: aluminium, seals: NBR, pilot: polyamide
Temperature range:
-5 to +60 °C
Operating pressure:
1,5 to 8 bar
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
<50 ms, max. 5 switching cycles/sec (5/3-way: max. 3 switching cycles/sec)
Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages
Voltage tolerance:
± 10 %
Protection class:
IP 65
Service life:
min. 40 million switching cycles
Structural shape solenoid coil:
T1 (plug size 1)
Information:
The coil and plug are enclosed as loose parts.
Body and slider: aluminium, seals: NBR, pilot: polyamide
Temperature range:
-5 to +60 °C
Operating pressure:
1,5 to 8 bar
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
<50 ms, max. 5 switching cycles/sec (5/3-way: max. 3 switching cycles/sec)
Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages
Voltage tolerance:
± 10 %
Protection class:
IP 65
Service life:
min. 40 million switching cycles
Structural shape solenoid coil:
T1 (plug size 1)
Information:
The coil and plug are enclosed as loose parts.
Properties
| Control voltage | 12 V DC |
| function | pulse valve |
| Thread G1 (2x) | G 1/4" |
| Thread exhaust air G1 (1x) | G 1/4" |
| Nominal width [mm] | 4,5 |
| flow [l/min] | 800 |
| Power consumption (DC) [W] | 3 |
| Spare solenoid coil | MAG T1 12V= |
| A [mm] | 163,4 |
| B [mm] | 35 |
| C [mm] | 22 |
| D [mm] | 8,2 |
| E [mm] | 69,2 |
| F [mm] | 25 |
| H1 [mm] | 4,2 |
| H2 [mm] | 3,3 |
| J [mm] | 17 |
| K [mm] | 66,7 |
| L [mm] | 30 |
| M [mm] | 70,5 |
| N [mm] | 22,5 |
| O [mm] | 82,7 |
| P [mm] | 1,5 |
| U [mm] | 67,5 |
| V [mm] | 40,5 |
| W [mm] | 0 |
Further information on RV3222-08-12V=
| Weight | 330 g / pcs |
| GTIN | 4050571714895 |
| Tariff No. | 84812090 |
| Manufacturer | EMC |
