MULTIFIX 3/2-way solenoid valve (NC), G 1/4", 24 V AC
Item number:
M CL 014 24VAC
Item description
Materials:
Body: die-cast zinc Z410 (model series 4 & 5: aluminium), cover: POM, diaphragms and seals: NBR
Media:
Oiled and unoiled compressed air, neutral gasses
Temperature range:
-10 to +60 °C
Advantages:
•Easy assembly of individual components using coupling kits within a model series and thread size.
Input pressure:
2 to 10 bar
Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages
Voltage tolerance:
± 10 %
Power consumption:
3 W / 5 VA (series 4: 2.5 W / 3 VA)
Protection class:
IP 65 (plug size 1, series 4: plug size 0C)
Scope of delivery:
Valve including silencer in exhaust thread
Body: die-cast zinc Z410 (model series 4 & 5: aluminium), cover: POM, diaphragms and seals: NBR
Media:
Oiled and unoiled compressed air, neutral gasses
Temperature range:
-10 to +60 °C
Advantages:
•Easy assembly of individual components using coupling kits within a model series and thread size.
Input pressure:
2 to 10 bar
Control voltages:
Standard: 24 V DC, 230 V AC, upon request other voltages
Voltage tolerance:
± 10 %
Power consumption:
3 W / 5 VA (series 4: 2.5 W / 3 VA)
Protection class:
IP 65 (plug size 1, series 4: plug size 0C)
Scope of delivery:
Valve including silencer in exhaust thread
Properties
| Version | 3/2-way solenoid valve (NC) |
| Model series | Multifix 0 |
| Thread | G 1/4" |
| Exhaust thread | G 1/4" |
| Electrical controls | 24 V AC |
| flow [l/min] | 1600 |
| H [mm] | 135 |
| H1 [mm] | 29 |
| L [mm] | 45 |
| Mounting brackets | W 0 |
| Coupling kit | KP 0 |
| Spare solenoid coil | M CL 24VAC |
Further information on MCL01424VAC
| Weight | 500 g / pcs |
| GTIN | 4050571853983 |
| Customs duty number | 84812090 |
| RoHS compliant | Yes |
Documents
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
