Item description
Materials:
Body: die-cast zinc Z410 (model series 4 & 5: aluminium), seals: NBR, oil tank: polycarbonate
Temperature range:
-10 to +60 °C
Media:
Compressed air, neutral gases
Advantages:
•Easy assembly of individual components using coupling kits within a model series and thread size.
Input pressure:
0 - 16 bar (with metal bowl max. 20 bar*)
Oil metering at 1000 l/min:
approx. 1 - 2 drops/min
Oil supply:
181 cm³
Lubricator reaction limit (at 6 bar):
115 l/min
Flow:
115 to 16000 l/min
Optional:
Version with metal bowl* and inspection tube -M
Advantages:
•can be filled with oil while under pressure
Body: die-cast zinc Z410 (model series 4 & 5: aluminium), seals: NBR, oil tank: polycarbonate
Temperature range:
-10 to +60 °C
Media:
Compressed air, neutral gases
Advantages:
•Easy assembly of individual components using coupling kits within a model series and thread size.
Input pressure:
0 - 16 bar (with metal bowl max. 20 bar*)
Oil metering at 1000 l/min:
approx. 1 - 2 drops/min
Oil supply:
181 cm³
Lubricator reaction limit (at 6 bar):
115 l/min
Flow:
115 to 16000 l/min
Optional:
Version with metal bowl* and inspection tube -M
Advantages:
•can be filled with oil while under pressure
Properties
Further information on OL104
| Weight | 1 kg / pcs |
| GTIN | 4050571852900 |
| Customs duty number | 84248970 |
| RoHS compliant | Yes |
Documents
*metal / glass combination drip cap
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
