Item description
Temperature range:
NBR: -35°C to max. +100°C, FKM: -15°C to max.+200°C
NBR: -35°C to max. +100°C, FKM: -15°C to max.+200°C
Properties
| Material | FKM |
| Thread type | metric |
| for threads | M 16x1,5 |
| d [mm] | 13,8 |
| D [mm] | 18,9 |
| S [mm] | 1,5 |
| Temperature range [°C] | -15 to +200 |
Further information on DRM16EDV
| Weight | 0,4 g / pcs |
| GTIN | 4050571270100 |
| Customs duty number | 39269097 |
| RoHS compliant | Yes |
YouTube videos:
Documents
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
