Item description
Temperature range:
+30 to +120 °C
Protection class:
IP 65, control output: max. 250 V AC, 30 V DC (0.1 to 4 A)
Electrical connection:
Right-angle connector installation size 3, 3-pole (DIN 43650 / EN 175301-803 A) (Flat pin)
Switching hysteresis:
max. 20 K
Connection:
G 3/4"
Optional:
Signal lamp in the plug (24 V DC, 0.1 - 1 A) -SL24, Signal lamp in the plug (230 V AC, 0.1 - 1 A) -SL220
+30 to +120 °C
Protection class:
IP 65, control output: max. 250 V AC, 30 V DC (0.1 to 4 A)
Electrical connection:
Right-angle connector installation size 3, 3-pole (DIN 43650 / EN 175301-803 A) (Flat pin)
Switching hysteresis:
max. 20 K
Connection:
G 3/4"
Optional:
Signal lamp in the plug (24 V DC, 0.1 - 1 A) -SL24, Signal lamp in the plug (230 V AC, 0.1 - 1 A) -SL220
Properties
| Material | Brass |
| Type of contact | NO contact |
| Switch point [°C] | +120 |
| Version | Standard |
Further information on TS34S120MS
| Weight | 135 g / pcs |
| GTIN | 4050571704049 |
| Customs duty number | 90321080 |
Documents
- Documentation (PDF)
- Data sheet (Print view)
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
