Item group

3/2-way valves - Futura, up to 12,500 l/min

Materials:

Body: PA 66 GF60, cover: POM, seals: NBR

Temperature range:

-10 to +50 °C

Media:

Oiled and unoiled compressed air, neutral gasses

Advantages:

•easy assembly of single components within a model series using coupling kits

Input pressure:

2 - 10 bar (pneumatically actuated: 2 - 16 bar, series 0: 2 - 12 bar)

Control voltages:

Standard: 24 V DC, 230 V AC, upon request other voltages

Voltage tolerance:

± 10 %

Power consumption:

2,5 W / 3 VA (50 Hz)

Protection class:

IP 65 (plug size 0C)

Scope of delivery:

Valve including silencer in exhaust thread

Documents:

More information Less information
3/2-way valves - Futura, up to 12,500 l/min:
20 of 31 articles
FUTURA 3/2-way solenoid valve (NC), G 1/4", 24 V DC, Futura 0(M CL 014 F 24V=)
M CL 014 F 24V=
FUTURA 3/2-way solenoid valve (NC), G 1/4", 24 V DC, Futura 0
€123.20 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/4", 230 V AC, Futura 0(M CL 014 F 230V)
M CL 014 F 230V
FUTURA 3/2-way solenoid valve (NC), G 1/4", 230 V AC, Futura 0
€123.20 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/4", 115 V AC, Futura 0(M CL 014 F 115V)
M CL 014 F 115V
FUTURA 3/2-way solenoid valve (NC), G 1/4", 115 V AC, Futura 0
€119.95 incl. VAT
Not in stock
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/4", , Futura 0(P CL 014 F)
P CL 014 F
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/4", , Futura 0
€84.74 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/4", 24 V DC, Futura 1(M CL 14 F 24V=)
M CL 14 F 24V=
FUTURA 3/2-way solenoid valve (NC), G 1/4", 24 V DC, Futura 1
€139.77 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 3/8", 24 V DC, Futura 1(M CL 38 F 24V=)
M CL 38 F 24V=
FUTURA 3/2-way solenoid valve (NC), G 3/8", 24 V DC, Futura 1
€139.77 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/4", 230 V AC, Futura 1(M CL 14 F 230V)
M CL 14 F 230V
FUTURA 3/2-way solenoid valve (NC), G 1/4", 230 V AC, Futura 1
€139.77 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 3/8", 230 V AC, Futura 1(M CL 38 F 230V)
M CL 38 F 230V
FUTURA 3/2-way solenoid valve (NC), G 3/8", 230 V AC, Futura 1
€139.77 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/4", 115 V AC, Futura 1(M CL 14 F 115V)
M CL 14 F 115V
FUTURA 3/2-way solenoid valve (NC), G 1/4", 115 V AC, Futura 1
€136.09 incl. VAT
Not in stock
FUTURA 3/2-way solenoid valve (NC), G 3/8", 115 V AC, Futura 1(M CL 38 F 115V)
M CL 38 F 115V
FUTURA 3/2-way solenoid valve (NC), G 3/8", 115 V AC, Futura 1
€136.09 incl. VAT
Immediately available
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/4", , Futura 1(P CL 14 F)
P CL 14 F
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/4", , Futura 1
€102.82 incl. VAT
Immediately available
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 3/8", , Futura 1(P CL 38 F)
P CL 38 F
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 3/8", , Futura 1
€102.82 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 3/8", 24 V DC, Futura 2(M CL 382 F 24V=)
M CL 382 F 24V=
FUTURA 3/2-way solenoid valve (NC), G 3/8", 24 V DC, Futura 2
€148.86 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/2", 24 V DC, Futura 2(M CL 12 F 24V=)
M CL 12 F 24V=
FUTURA 3/2-way solenoid valve (NC), G 1/2", 24 V DC, Futura 2
€148.86 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 3/8", 230 V AC, Futura 2(M CL 382 F 230V)
M CL 382 F 230V
FUTURA 3/2-way solenoid valve (NC), G 3/8", 230 V AC, Futura 2
€148.86 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 1/2", 230 V AC, Futura 2(M CL 12 F 230V)
M CL 12 F 230V
FUTURA 3/2-way solenoid valve (NC), G 1/2", 230 V AC, Futura 2
€148.86 incl. VAT
Immediately available
FUTURA 3/2-way solenoid valve (NC), G 3/8", 115 V AC, Futura 2(M CL 382 F 115V)
M CL 382 F 115V
FUTURA 3/2-way solenoid valve (NC), G 3/8", 115 V AC, Futura 2
€144.97 incl. VAT
Not in stock
FUTURA 3/2-way solenoid valve (NC), G 1/2", 115 V AC, Futura 2(M CL 12 F 115V)
M CL 12 F 115V
FUTURA 3/2-way solenoid valve (NC), G 1/2", 115 V AC, Futura 2
€144.97 incl. VAT
Immediately available
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 3/8", , Futura 2(P CL 382 F)
P CL 382 F
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 3/8", , Futura 2
€158.53 incl. VAT
Immediately available
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/2", , Futura 2(P CL 12 F)
P CL 12 F
FUTURA 3/2-way pneumatic valve (NC, G1/8"), G 1/2", , Futura 2
€158.53 incl. VAT
Immediately available
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
