Item group
5/2-way solenoid valves G 1/8", Series SC300 (will be discontinued)
Materials:
Body and slider: aluminium, seals: NBR, pilot: polyamide (glass fibre reinforced)
Temperature range:
-10 to +60 °C
Media:
oiled and unoiled filtered compressed air
Switching time (at 5 bar):
< 25 ms
Control voltages:
24 V DC
Voltage tolerance:
± 10 %
Power consumption:
1,2 W
Protection class:
IP 50
Version:
with 2-pole connector, and LED (including 600 mm cable, 5 mm plug width)
Information:
These valves are always supplied with a solenoid coil and a connector plug.
More information
Filter items
5/2-way solenoid valves G 1/8", Series SC300 (will be discontinued):
1 of 1 articles
SC320DF PL-D4
5/2-way solenoid valve, G 1/8", pulse valve, 24 V=
€122.24
incl. VAT
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
