-20°C to max. +100°C (Type 1.4404: -20°C to max. +120°C)
Media:
lubricating media (e.g. hydraulic oil or oiled compressed air)
Field of application:
Between a fixed point and a hose on rotating or oscillating machine components. Hose can vibrate and rotate due to the slide bearing shaft under maximum pressure loading.
Warning:
To balance out alignment inaccuracies, the use of a flexible connection is imperatively recommended.
*temperature values, pressures and revolutions per minute are maximum values which should not happen simultaneously. Please contact us to select the correct swivel joint for your operating case.
{{ $t('shop.all.dokumente') }}:
Catalogue page Atlas 9 (Page 185) atlas9_seiten/185.pdf
Documentation doku/dreh.pdf
Assembly instructions for NC compression ring fittings
Assembly instructions for cutting ring fittings
The advantage of swivel joints and swinging screw connections for compressed air, water and oil!
