DUOPOWER dowels- 2 component, FISCHER

Description

Application:
Concrete and solid brick wall materials, honeycomb brick, hollow block made of light concrete, hollow ceilings made of tiles and concrete, aerated concrete, plaster, particle boards, etc. For wall assembly, the dowel must be placed flush in the carrying underground; for manifold assembly, please observe minimum board thickness.

Screws that can be used:
Wood or chipboard screws

Advantages:
•two material components (Nylon + PP) for best loading values and reliable function (spreading, folding), depending on construction material, •the short dowel lengths enable fast assembly thanks to smaller borehole depth, •as long version with higher loading capacity in perforated materials, aerated concrete or for plaster bridging, •the narrow dowel edge prevents the deep slipping of the dowel in the borehole

*not suitable for manifold assembly

Find the right item

Version
Drill Ø [mm]
Min. hole depth [mm]
Dowel length [mm]
min. board thickness [mm]
Screws Ø [mm]
Amount

DUOPOWER dowels- 2 component, FISCHER: 9 of 9 items

FISCHER dowels, DUOPOWER 5x25, 100 pack
  • Version

    Standard

  • Drill Ø [mm]

    5

  • Min. hole depth [mm]

    35

  • Dowel length [mm]

    25

  • min. board thickness [mm]

    12,5

  • Screws Ø [mm]

    3 - 4

Immediately available

5,20 €

FISCHER dowels, DUOPOWER 6x30, 100 pack
  • Version

    Standard

  • Drill Ø [mm]

    6

  • Min. hole depth [mm]

    40

  • Dowel length [mm]

    30

  • min. board thickness [mm]

    12,5

  • Screws Ø [mm]

    4 - 5

Immediately available

7,23 €

FISCHER dowels, DUOPOWER 8x40, 100 pack
  • Version

    Standard

  • Drill Ø [mm]

    8

  • Min. hole depth [mm]

    50

  • Dowel length [mm]

    40

  • min. board thickness [mm]

    12,5

  • Screws Ø [mm]

    4,5 - 6

Immediately available

10,50 €

FISCHER dowels, DUOPOWER 10x50, 50 pack
  • Version

    Standard

  • Drill Ø [mm]

    10

  • Min. hole depth [mm]

    60

  • Dowel length [mm]

    50

  • min. board thickness [mm]

    12,5

  • Screws Ø [mm]

    6 - 8

Immediately available

10,02 €

FISCHER dowels, DUOPOWER 12x60, 25 pack
  • Version

    Standard

  • Drill Ø [mm]

    12

  • Min. hole depth [mm]

    70

  • Dowel length [mm]

    60

  • min. board thickness [mm]

    *

  • Screws Ø [mm]

    8 - 10

Immediately available

7,61 €

FISCHER dowels, DUOPOWER 14x70, 20 pack
  • Version

    Standard

  • Drill Ø [mm]

    14

  • Min. hole depth [mm]

    80

  • Dowel length [mm]

    70

  • min. board thickness [mm]

    *

  • Screws Ø [mm]

    10 - 12

Immediately available

11,28 €

FISCHER dowels, DUOPOWER 6x50, 100 pack
  • Version

    Long version

  • Drill Ø [mm]

    6

  • Min. hole depth [mm]

    60

  • Dowel length [mm]

    50

  • min. board thickness [mm]

    12,5

  • Screws Ø [mm]

    4 - 5

Immediately available

12,74 €

FISCHER dowels, DUOPOWER 8x65, 50 pack
  • Version

    Long version

  • Drill Ø [mm]

    8

  • Min. hole depth [mm]

    75

  • Dowel length [mm]

    65

  • min. board thickness [mm]

    25,0

  • Screws Ø [mm]

    4,5 - 6

Immediately available

9,38 €

FISCHER dowels, DUOPOWER 10x80, 25 pack
  • Version

    Long version

  • Drill Ø [mm]

    10

  • Min. hole depth [mm]

    90

  • Dowel length [mm]

    80

  • min. board thickness [mm]

    *

  • Screws Ø [mm]

    6 - 8

Immediately available

8,89 €

All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
