Way valves NG 6 electically operated in piston design, up to 40 l/min*

These solenoid-operated way valves are used in hydraulic systems predominantly for starting, stopping and changing the direction of flow of the liquid. Using NG 6 the pressure valve, the flow control valve and the check valve sandwich plates are arranged like a stack to form a circuit in the smallest space possible.

Body: Spheroidal cast iron, internal parts: Steel, seals: NBR

-30 to +80 °C

Hydraulic oils on the basis of mineral oil (viscosity: Bosch Rexroth: 2,8 - 500 mm²/s, alternatively: 20 - 400 mm²/s)

Standard: 24 V DC, 230 V AC, upon request other voltages

± 10 %

IP 65

0 to 350 bar

Up to approx. 80 l/min (request pressure loss curves if required), we recommend usage up to approx. 40 l/min

The connection pattern NG 6 is standardised in accordance with DIN 24340-A6 / ISO 4401-03 (NG 6) / CETOP R 35 H-03 and NFPA-D03. The valves must be attached with screws of strength class 12.9.

Valve including seals, without screws and plugs.

Please do not forget to order screws and valve plugs.
