Item description
Application:
Extremely high-density thread sealing tape for high-quality thread sealing up to 690 bar (liquids max. 690 bar, liquid oxygen max. 300 bar, gases max. 170 bar)
Temperature range:
-240 to +260 °C
Media:
Air, water, nitrogen, gas, propane, butane, ammonia, hydrogen, oxygen, solvents, acids, alkalis, fuels, refrigerants, steam
Density:
approx. 100 g/m²
Approvals:
UL, MIL-T-27730A, FDA 21 CFR 177.1615, NSF H1 (Reg. 134016), BAM for oxygen (max. 30 bar, max. +100°C)
Class:
GRp
Advantages:
•threaded connection can be adjusted up to 90°,
•approved for oxygen
•requires less windings,
• minimises the danger of clogging of the pipelines due to a high resistance to tears and fractures.
Extremely high-density thread sealing tape for high-quality thread sealing up to 690 bar (liquids max. 690 bar, liquid oxygen max. 300 bar, gases max. 170 bar)
Temperature range:
-240 to +260 °C
Media:
Air, water, nitrogen, gas, propane, butane, ammonia, hydrogen, oxygen, solvents, acids, alkalis, fuels, refrigerants, steam
Density:
approx. 100 g/m²
Approvals:
UL, MIL-T-27730A, FDA 21 CFR 177.1615, NSF H1 (Reg. 134016), BAM for oxygen (max. 30 bar, max. +100°C)
Class:
GRp
Advantages:
•threaded connection can be adjusted up to 90°,
•approved for oxygen
•requires less windings,
• minimises the danger of clogging of the pipelines due to a high resistance to tears and fractures.
Properties
| Thickness [mm] | 0,09 |
| Width [mm] | 12,7 |
| Roll length [MTR] | 4,6 |
Further information on DBTFL
| Weight | 20 g / pcs |
| GTIN | 4050571245818 |
| Customs duty number | 39219090 |
| Manufacturer | Chesterton |
YouTube videos:
Documents
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
