Valve function | Throttle blowback function |
Pneumatic connection 1 | M5 |
Pneumatic connection 2 | M5 |
Setting element | knurled screw |
Fastening type |
Front panel integration, With throughway bores, Selectively: |
Normal nominal flow in one-way flow control [l/min] | 115,0 |
Normal nominal flow in check valve direction [l/min] | 130 to 137 |
Operating pressure [bar] | 0.5 to 10 |
ambient temperature [°C] | -20 to 60 |
Housing material | Aluminium wrought alloy |
installation position | arbitrary |
Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
Information about operating and control medium | Oiled operation possible (required in further operations) |
Medium temperature [°C] | -20 to 60 |
Nominal width [mm] | 2 |
Material information | RoHs compliant |
Seals material | NBR |
Sleeve material | POM |
Regulation screw material | High-alloyed steel |
Nut material | Aluminium wrought alloy |
Peso | 20 g / Udad |
GTIN | 4052568010683 |
Código aduanero | 84812090 |
Fabricante | Festo |
