Opis artikla
Power supply:
24 - 230 V AC, 24 - 48 V DC
Temperature range:
-10 do +55 °C
Control input:
20.4 - 253 V AC or 20.4 - 52.8 V DC
Control output:
Changeover relay, 5 A at 250 V AC, 30 V DC (resistive load)
Time range:
0.1 s to 120 h
Protection class:
IP 30, terminal block (screw connection): IP 20
Operating types:
A: Response delay, B: Pulse generator with pause start, B2: Pulse generator with pulse start, C: Signal ON / OFF delay, D: Relapse delay, E: Signal ON delay, G: Response and relapse delay, J: Reponse delayed pulse relay
24 - 230 V AC, 24 - 48 V DC
Temperature range:
-10 do +55 °C
Control input:
20.4 - 253 V AC or 20.4 - 52.8 V DC
Control output:
Changeover relay, 5 A at 250 V AC, 30 V DC (resistive load)
Time range:
0.1 s to 120 h
Protection class:
IP 30, terminal block (screw connection): IP 20
Operating types:
A: Response delay, B: Pulse generator with pause start, B2: Pulse generator with pulse start, C: Signal ON / OFF delay, D: Relapse delay, E: Signal ON delay, G: Response and relapse delay, J: Reponse delayed pulse relay
Dodatne informacije o H3DSML
| Teža | 80 g / Kos |
| GTIN | 4050571349967 |
| Številka carinskega blaga | 85364900 |
| Proizvajalec | Omron |
Dokumenti
- Catalogue page Pneumatic Atlas 8 (Page 745a) (PDF)
- Podatkovni list (Pogled za tiskanje)
- Podatkovni list (angleščina) (Pogled za tiskanje)
