Opis artikla
Operating range:
Pneumatic pinch valves are the fitting solution for the shut-off, regulation and dosing of abrasive, corrosive and fibrous products. They are ideally suited for use with these products due to their completely free product flow, whereby a practical blocking and dead space-free fitting results. The pneumatic pinch valves ensure an optimal shut-off, also when used with solids, such as granules, powders, pellets, chipping, sand, cement, gravel, textile fibres, carbon, fine glass fragments and liquids that contain solids.
Advantages:
•Completely free flow,
•No clogging by media,
•Minimum frictional resistance,
•Quick opening and closing,
•Low energy consumption
Materials:
Body: Type stainless steel: 1.4408, aluminium type: powder-coated aluminium, type POM: POM, socket: 1.4408 (type POM: POM), cuff: light-coloured natural rubber in food quality
Operating pressure:
0 do 6 bar
Control pressure:
max. 2 bar higher than the medium's pressure
Temperature range:
-10°C to max. +80°C
Optional:
Natural rubber sleeve, abrasion resistant (-10°C to max. +80°C) -AB, EPDM sleeve (-10°C to max. +120°C) -EP
Pneumatic pinch valves are the fitting solution for the shut-off, regulation and dosing of abrasive, corrosive and fibrous products. They are ideally suited for use with these products due to their completely free product flow, whereby a practical blocking and dead space-free fitting results. The pneumatic pinch valves ensure an optimal shut-off, also when used with solids, such as granules, powders, pellets, chipping, sand, cement, gravel, textile fibres, carbon, fine glass fragments and liquids that contain solids.
Advantages:
•Completely free flow,
•No clogging by media,
•Minimum frictional resistance,
•Quick opening and closing,
•Low energy consumption
Materials:
Body: Type stainless steel: 1.4408, aluminium type: powder-coated aluminium, type POM: POM, socket: 1.4408 (type POM: POM), cuff: light-coloured natural rubber in food quality
Operating pressure:
0 do 6 bar
Control pressure:
max. 2 bar higher than the medium's pressure
Temperature range:
-10°C to max. +80°C
Optional:
Natural rubber sleeve, abrasion resistant (-10°C to max. +80°C) -AB, EPDM sleeve (-10°C to max. +120°C) -EP
Lastnosti
| Material | Nerjavno jeklo |
| Izvedba | Potisni ventil, manšeta iz naravne gume (kakovost, primerna za živila) |
| G | G 1/2" |
| DN | 15 |
| L | 134 |
| A | G 1/4" |
| Nadomestna manšeta iz naravne gume (kakovost, primerna za živila) | QVM 12 ES MANSCHE |
| Nadomestna manšeta iz naravne gume (odporna proti obrabi) | QVM 12 AB MANSCHE |
| Nadomestna manšeta EPDM | QVM 12 ESEP MANSC |
| Temperaturno območje | od -10 do +80 |
Dodatne informacije o QVM12ES
| Teža | 1,6 kg / Kos |
| GTIN | 4050571562168 |
| Številka carinskega blaga | 84818087 |
YouTube videi:
Dokumenti
- Catalogue page Atlas 9 (Page 529) (PDF)
- Dokumentacijo (PDF)
- Podatkovni list (Pogled za tiskanje)
- Podatkovni list (angleščina) (Pogled za tiskanje)
*Body POM
Vse navedbe podatkov so nezavezujoče orientacijske vrednosti! Za izbiro podatkov, za katere ne izdamo pisnega potrdila, ne prevzemamo jamstev. Navedbe tlaka, v kolikor ni navedeno drugače, se nanašajo na tekočine skupine II. pri +20°C.
