Design | round |
Permission | RCM mark |
CE certificate (see declaration of conformity) | to EU EMC directive |
Material information | Copper and PTFE-free |
Measurement principle | Reed magnetic |
ambient temperature [°C] | -20 to 60 |
Control output | Bipolar contact |
Switching element function | NO contact |
Reproducibility of the switching value | ± 0,1 mm |
Switch on time [ms] | <= 0,5 ms |
Switch off time [ms] | 0,03 |
Max. output current [mA] | 500 |
Max. switching capacity DC [W] | 10 |
Short circuit resistance | no |
Operating voltage range DC [V] | 12 to 27 |
Reverse polarity protection | no |
Electrical connection |
M8x1, 3 pin, Plug |
Fastening type | With Accessories |
Housing material | PET |
Switching status indicator | LED yellow |
Protection category | IP67 |
hmotnost | 11 g / ks |
GTIN | 4052568069971 |
Celní číslo zboží | 85365019 |
výrobce | Festo |
