Item group
Safety position switch, Metal
Materials:
Housing: metal
Temperature range:
-40 to +80 °C
Electrical connection:
Screw terminals, cable gland: M 20x1,5 (FT)
Protection class:
IP 67
Switch type:
1 Opener (NC) and 1 Closer (NO)
Switching capacity:
400 V (AC), max. 10 A / 30 V (DC), max. 6 A
Minimum switch load:
Ohmic load of 120 mA at 5 V DC
Actuator:
can be rotated by 90° in 4 positions
Documents:
More information
Filter items
Safety position switch, Metal:
10 of 10 articles
€65.93
incl. VAT
€60.45
incl. VAT
€70.63
incl. VAT
€65.93
incl. VAT
€54.51
incl. VAT
€81.34
incl. VAT
€81.34
incl. VAT
€81.34
incl. VAT
deliverable again in ⌀ 2 days
€81.34
incl. VAT
€54.51
incl. VAT
All data are to be understood as non-binding reference values! We do not assume liability for any data selection not confirmed in writing. Unless otherwise specified, pressure values refer to liquids from Group II at +20°C.
